Kraus Motor EOS Denali D14 Headlight Kit - 2025–2026 Low Rider ST | SF-LT-12

For 2025–2026 Low Rider ST with matching factory fairing and electrical interface. Includes one Denali D14 headlight, aluminum mounting bracket and harness. Lamp dimensions: 6.75-inch diameter by 3-inch depth; 9–32 VDC, maximum 105 W/8 A. Yellow/amber X-lenses are sold separately, one per pack. Denali’s limited lifetime coverage applies to the D14 lamp only; brackets and harness are excluded. Photograph shows the product series; select the correct model-year interface.

Specifications

• Brand: Kraus Motor
• Manufacturer part number: SF-LT-12
• SF-LT-12: 2025–2026

Supply and delivery

• Overseas warehouse. Estimated delivery: 7–10 business days.

Installation notes

• Remove the OEM headlight/fairing; clear coating debris from threads. Support-bracket screws use a little threadlocker and 6 ft-lb. Use supplied low-profile M8 screws at the lamp and confirm aim before final fastening. D14 high beam selects either blue DOT/SAE or orange ECE wiring using the connector lock; isolate the unused lead. Certification wording is not Taiwan vehicle approval. Check harness slack at full steering lock and suspension compression; inspect hardware after 30 miles. Manufacturer recommends a battery maintainer when parked due to possible increased draw. Have a qualified technician follow the matching vehicle and kit manuals, test slowly and recheck. Improper installation can cause severe injury or death.
• Manufacturer installation guide: https://krausmotorco.com/content/pdfs/EOS-Light-Kit-With-Denali%20Lighting-For-Low-RIder-ST-Instructions.pdf
• Manufacturer installation guide: https://cdn.shopify.com/s/files/1/0030/3408/7524/files/DNL.IM.D14.050_Rev00.pdf?v=1728407737
